This boat has more than $60k worth of additional upgrades and improvements including new chain plates, standing rigging and running rigging.This is a Whitby unlike any other and an outstanding opportunity to own a boat that has years of service and value at this price. CALL THE LISTING BROKER FOR MORE DETAILS.
Boat configuration
• Center cockpit cutter rigged ketch
• Extended bowsprit with cutter rig
• Removable deck-tacked staysail forestay
• Displacement: 23,500 lbs designed, but about 30,000 lbs fully loaded
• Rudder enlarged on back edge and at bottom per designer (Ted Brewer) and completely rebuilt and reinforced (2012)
• Two sleeping cabins,
• two heads,
• main salon,
• galley,
• workbench,
• nav station
• Salon has very large folding table, additional table on starboard dropping down from wine rack,
• L-shaped settee on port with 2 swiveling captain’s chairs on starboard
• Teak and holly sole throughout interior
Engine room and Propulsion
• Volvo MD-30 (60 Hp) 4 cyl. Diesel engine with approx. 3100 hours
• Westerbeke 4.4 Kw Diesel generator with approx 1660 hours
• MaxProp (18”) 3 blade feathering propeller
• PSS Shaft Seal (Stuffing Box)
• Driveline Shaft Saver installed
• “Fire – Boy” Halon automatic fire extinguisher in engine room
• Refrigeration compressor and pump – Grunert 110v AC
• Webasto FCF series 16000 Btu heating & air conditioning (ducted to all cabins) (new 2019)
• Dual Racors – type 500FG selectable with polishing system
• Fuel tanks – 60 gallon each port and starboard, (90 gallon keel tank disabled)
• Fuel line selector for intake and return fuel lines
• “Hynautic” steering – Edson tiller arm rebuilt (2021), hydraulic pump rebuilt (2023)
Sails and Rigging
• Main – fully battened two reef points with Dutchman Flaking System
• Genoa – 127% roller furled (new 2005)
• Mizzen – fully battened with lazy jacks
• Spinnaker – cruising asymmetrical, deck tacked, dousing sock
• Mizzen staysail – reaching sail, mizzen boom tack
• All sails in good condition
Cockpit Canvas
• Complete dodger and bimini enclosure, new bimini windows (2021), new dodger windows (2024)
• S&S 2” closed cell foam (non-absorbing) cockpit cushions
Cockpit and Helm Station
• Port lazerette opens to engine room and contains Webasto FCF – air cond/heater.
• Insulated lazerette under helm seat which can be used as ice chest.
• Teak covered cockpit seating
• Winches: all refurbished in 2024
o 2 Lewmar #55 2-speed self-tailing winches for Jib sheets (one on port side of cockpit and one on starboard side of cockpit)
o 2 Lewmar #43 2-speed self-tailing winches (one on port side of cockpit and one on starboard side of cockpit) The Harken Cruising II roller furling control line brought to starboard side Lewmar #43 winch with running blocks and ratchet block on aft end
o 1 Lewmar #30 2-speed self-tailing winch on starboard side of main mast to handle Main sheet.
o 1 Lewmar #20 2-speed self-tailing winch on port side aft deck of cockpit to handle Mizzen sheet.
• “Ritchie” binnacle compass (backlit red with running or masthead lights on)
• Engine electrical controls, forward/reverse gear shift and throttle controls
• Engine warning lights, water temp and oil pressure gauges
• Fuel tank gauge and switches for port and starboard fuel tanks
• Halon fire extinguisher indicator light
• Electronics: NEW IN 2024
o B&G Zeus S 9” chartplotter
o Two B&G Triton2 multifunction displays
o B&G DST810 thru hull for boat speed, depth and water temperature
o B&G WS310 masthead wind sensor
o B&G ZG100 GPS antenna
o B&G NAC-3 Autopilot computer (purchased but not yet installed)
o B&G Triton2 Autopilot control keypad
o B&G Precision 9 Compass
o B&G RF25N Rudder Feedback Unit
o NMEA2000 backbone network to connect all B&G electronics
• VHF radio – CommandMIC (dual with nav station)
• Icom Ic-802 SSB radio (installed except for antenna which was not replaced on back stays when standing rigging was replaced)
• Companion way (fore and aft) sliding covers and louvered drop slides (2) as well as full screens (2) and clear Plexiglas (2)
Foredeck
• Bowsprit extension – (stainless & teak) supported by ¾” stainless bobstay (teak and starboard chain guard.
• Inner forestay for staysail (deck tacked and removable with Highfield lever)
• Harken Cruising II roller furler
• Maxwell windlass with foot control switch (rebuilt 2018, new motor brushes 2023)
• Anchor 45# Manson supreme on bow mount with 150 ft 3/8” BBB chain in anchor locker below
• Anchor 45# Bruce as alternative, with 150 ft 3-strand nylon rode
• Forespar whisker pole stowed on mast
• Two Mobri S-2 radar reflectors on shrouds at spreaders
• Deck light (LED)mounted on main mast spreaders
• Bomar opening hatches (2) with smoked glass covers
• Easily removable locking security bars in all top hatches
• Dorade boxes (2) with air scoops
Aft deck
• Starboard lazerette storage for dock lines (4) and fenders
• Port lazerette for propane tanks (2), propane regulator, and fuel cans
• Outboard engine storage mount by Edson on aft rail
• Swim ladder with extension by “Tops in Quality” on stern
• Deck light mounted on mizzen mast spreaders
• Dorade box with air scoop Aft
Water and plumbing system
• 12 gallon hot water tank – heated by engine or 110 v. power (new 2018)
• Jabsco water pump with additional accumulator
• 40 gallon waste holding tank – overboard outlets (locked) for head discharge
• Jabsco Macerator pump for discharge of holding tank in safe sea zones (offshore)
• Deck plate access for holding tank pump out
• Two 110-gallon water tanks beneath cabin sole in salon (cleaned in 2024)
• One 70-gallon water bow tank bow in V-berth
• Head flush water selectable valve for fresh or salt water
• Deck wash with selectable valve for fresh or salt water
• Shower sump pumps (2) for showers in fore and aft heads
• Airhead composting toilet in aft stateroom.
• Jabsco marine toilet in forward head (new 2024) seawater or freshwater flush.
• Raritan 1-1/2” Sani/Flex waste hose from forward head to holding tank (new 2024)
Electrical System
• House battery – 2 (with room for 2 more) heavy duty 6volt golf cart batteries in series (batteries new 2020)
• Engine starting battery 2 (new 2024)
• Generator starting battery (Gp 24) eng room
• Windlass battery (Gp 24) in anchor locker with 100 A. breaker (new 2024)
• GoPro 3000 watt inverter
• Promariner ProNautic 10-60P 3-bank, 60 A. programmable battery charger powered by 110 v. (generator or shore power)
• 160 A alternator on engine for charging with Volvo diesel
• Two 30 A. shore power receptacles on aft cabin starboard
• Marinco 30 A. shore power cord and 50 A. to 30 A. splitter
• Power cord adapter for 20 amp shore power to 30 A. connector
• Guest battery selector switches (2) – house/engine/both & generator – on off
• AC 110 v. electrical outlets (8) throughout the boat
• DC 12 v. receptacle over workbench
Galley
• Three burner propane stove and oven (Hillerange) – with gimble lock and security strap
• Propane safety valve control
• Microwave oven -110 volt, 1000watt (Whirlpool)
• Grunert Versamatic freezer and refrigerator compressor (rebuilt 2012) Fridge has both top and side loading door
• Freezer 15”D x 29”H x 24”W – Refrigerator 15”D x 29”H x 29”W
• Dual stainless sinks
• Galley sink faucet with pull out spray hose (new 2023)
• Filtered fresh water faucet (separate)
• Sea water faucet with foot pump (separate)
• Bomar opening hatch above stove
Main Salon
• L-shaped settee in Sunbrella to port – becomes double berth
• Two removable swivel chairs in Sunbrella to starboard
• Drop-down teak dining table with leaf – built-in bookcase/pantry behind table
• Bar with drop-down table and interior light to starboard
• Entertainment area behind door next to bar
• Nav station seat in Sunbrella
• Hanging locker forward to starboard with shelves in back of hangers
• Wet locker at bottom of companion way stairs
• Door access to forward head
• Bomar overhead opening hatch in center of salon cabin
• Salon opening portlights Newfound Metals new 2018 – port (2) & starboard (2)
• All portlights throughout the boat replaced in 2018 with Newfound metals locking ports, with screens and tempered glass windows. 12 ports total.
• Reading lights (Ondine) – port (1) & starboard (1) on forward wall
• Electric fans (Sirocco II™ Fan from by Caframo) – 1 port &1 starboard on forward wall (both new 2023)
• Stereo speakers in forward wall of salon
• LED track lighting and bulbs on most light fixtures
•
Nav Station
• VHF radio – ICOM 502 with DSC and CommandMIC remote (in cockpit)
• Radar – Raymarine SL-72 Plus (2004) – not sure if operational
• Data logger – Datamarine Model A181 – total miles, trip miles and reset
• Brass barometer and clock (Trident)
• Icom IC-802 SSB radio (antenna not connected)
Forward Cabin
• V-berth with filler insert for added center support
• Berths become sea berths with fold-up lee boards
• Hanging locker to starboard with shelves on top and in back of hangers
• Door to hanging locker opens to become door to main salon
• Shelves above each berth (3 doors on each side)
• Drawer and storage bin under each berth
• Bomar overhead opening hatch with footstep for easy egress
• LED Reading lights over each berth and electric fan over starboard berth
• Door access to forward head – private access with salon door closed
• Access to anchor locker
Aft Berth Cabin
• Berths or queen athwartships with memory foam mattress (new 2018)
• Private access to aft head
• Double door hanging locker with shelf storage
• Night stand bureau with drawers on strbd between locker and strbd berth
• Shelves (2) with door in locker above bureau
• Drawer and storage bin under each berth
• Shelves above each berth (3 doors each side)
• Reading lights over each berth (2), LED on starboard lamp
• Companion way ladder to aft companion way with overhead slider
• Access under berth to rudder post for emergency tiller and to hydraulic cylinder
• Access through floor to PSS shaft seal, drive shaft, and bilge pumps
Safety Systems
• Carbon monoxide detector on workbench wall across from engine room
• Fire extinguishers (3) mounted in aft cabin, galley, and V berth
• Personal Flotation Devices – 6 adult and 3 children
• Bell stored behind work bench for mounting on mizzen mast
• MOB Lalizas lifesling on aft rail (new 2024)
• MOB horseshoe collar throw ring on aft rail
Entertainment
• CD AM-FM radio Sony CDX-GT620IP (2008) with Ipod aux input with remote (needs to be replaced)
• Stereo speakers in main salon, aft cabin, & cockpit –selectable
Other systems and upgrades
• Cato davits
• Harken Cruising II roller furler, foil, halyard, and outhaul (2013)
• Magma barbeque grill
• Teak toe-rail sanded and Cetol Nartural Light applied to most of it
• Cockpit seating teak grout removed and replaced with Teakaflex
• Masthead LED Anchor/Tricolor light (new 2024)
• Boat was to be bottom painted, and a few blisters were found in 2015. Entire hull below waterline was sanded, any blisters professionally repaired, and then 9 barrier coats of epoxy applied before bottom painting. Expense was approximately $10,000. The boat bottom is in excellent shape.
Spares
This boat has numerous spare parts and equipment/tools that go with the boat. There are too many to list.
